19
2. Scope of delivery
KBN: FLOWTP30
Submersible pump, ready for plugging in, with 10 m cable and Schuko plug, built-in
adjustable oat switch, 1½" pressure outlet with female thread and 1¼" pressure
outlet with male thread.
KBN: FLOWTP30 OS
Submersible pump, ready for plugging in, for switchgear operation, with 10 m cable
and Schuko plug, 1½" pressure outlet with female thread and 1¼" pressure outlet with
male thread.
3. Application
> FLOW submersible pump 30 series is suitable for pumping clear water, rainwater,
domestic wastewater without faecal matter, and a solids content up to
0.5 % max. (maximum solids passage of diameter 30 mm).
> The pumps may not be used to pump corrosive, ammable, gaseous or potentially
explosive uids or sewage containing faecal matter. Fluids containing sand or other
abrasive substances reduce the service life of the pumps.
> The noise emission value is less than 70 dB (A).
> If damage can occur due to a failure of the pumping station, for example due to a
power failure or technical defect, an alternative system must be available as back-
up e. g. emergency power supply, double pumping station, network-independent
alarm, etc.
4. Materials
Materials
Pump housing EN-GJL-250
Impeller Polyamide
Seals NBR
Motor shaft Stainless steel 1.4057 (AISI 431)
Upper lid Polypropylene (PP)
Fasteners Stainless steel 1.4401 (AISI 316)
Technical data
