20
5. Technical data
Technical data
Article number FLOWTP30 & FLOWTP30 OS
Pressure outlet
> G 1½" female thread
> Adapter G 1¼" male thread
Max. ow (at 1 m) 18 m
3
/h
Max. head (at 0 m
3
/h) 8.5 m
Free passage 30 mm
Power cable (plug-in / EasyFit) H07RN-F 3G1.0
Mechanical seal Silicon carbide / carbon
Cable length 10 m
Weight Approx. 8.5 kg
Voltage/frequency 1 x 230 V/50 Hz
Current type Alternating current
Nominal current 3.6 A
Motor power P1 0.8 kW
Speed 2900 rpm
Motor protection Temperature monitor built into winding
Plug Schuko plug
Protection class IP 68
Motor insulation class B
Motor protection activation
temperature
120 °C
Maximum immersion depth 10 m
Fluid temperature Max. 40 °C (60 °C for 5 minutes)
Pump curve – see page 24, gure 2, Dimensions – see page 25, gure 4
Transport / Electrical connection/ Set-up/installation
