29
Problem Solution
During operation • The device re-heats. Once the re-heating process is
finished, suddenly the device puts out fog again.
there is no more fog. • The device is no longer connected tot he voltage sup-
ply. Check the correct connection and the voltage
supply of the outlet.
• The tank is empty and needs refilling.
The device re-fogs. • This is not a defect. The remaining fog liquid in the hot
after letting go fog in the fog output evaporates.
button or after turning
off/unplugging for a
short time.
Repairs other than those described above should only be performed
by an authorised electrician.
Technical data
I-180 I-280 I-380 I-580X
Operating voltage 230 V~/50 Hz
Power consumption 700W 1000W 1200W 1300W
Fuse (5x20mm) F3,15A F5A T6,3A 10A
Pre-heating time 5min 5min 10min 10min
max. burst duration 30s 20s 25s 12s
Tank volume 0.8l 1.3l 2.5l 6l
Fog liquid consumption 400ml/h 1,224.5ml/h 1,363.6ml/h 5,000ml/h
Fog output 70m3/min 140m3/min 500m3/min 510m3/min
Remote control cable 3m 3m 3m 10m
suitable fog liquid Order no.: 590775 (1l)
Order no.: 595900 (5l, normal)
Order no.: 595918 (5l, heavy)
suitable
cleaning liquid Order no.: 590298
DMX protocol —- —- DMX-512 DMX-512
DMX channels —- —- 1 1
Dimensions 330 x 160 x 390 x 180 x 435 x 250 x 560 x 255 x
160mm 205mm 220mm 225mm
Weight 3.3kg 5.3kg 9.5kg 12kg
