26
Intended Use
The range of use of the "5-channel Club Mixer Mc Crypt DJ-3000” consists of use in
music systems in the home as well as semi-professional environments.
The device is used for mixing and controlling low-level audio signals. The device is,
thereby, switched between the audio signal source to be controlled and an audio
amplifier.
This product is licensed for connection to 230V~/50Hz alternating current.
Use is only permitted in closed and dry rooms. Any contact with dampness must be
avoided at all times.
Any other use than that described above can lead to damage to this product and, in
addition, is associated with risks such as, for example, shorts, fire, electric shock
etc.
No part of the product may be altered or converted or the housing opened!
The safety instructions must be observed at all times!
Table of contents
Introduction ..............................................................................................................25
Intended use ............................................................................................................26
Table of contents ......................................................................................................26
Product description ..................................................................................................27
Explanation of symbols ............................................................................................27
Safety instructions and indication of risks................................................................28
Connecting and operating elements ........................................................................29
Setting up the device................................................................................................35
Connection................................................................................................................36
Connection of inputs ............................................................................................36
Connection of outputs ..........................................................................................37
Connection of fader start outputs ........................................................................38
Connection of power supply ................................................................................38
Commissioning ........................................................................................................39
Handling....................................................................................................................41
Servicing and maintenance ......................................................................................41
Disposal ....................................................................................................................42
Elimination of disturbances ......................................................................................42
Technical data ..........................................................................................................44
43
Problem Possible cause Elimination of error
MASTER slide control is Adjust slide control
at position "0”. MASTER 1 (12) correctly
Channel fader (3) Set channel fader correctly
on position "0”
No signal can be Downstream device Check downstream device,
heard although the (amplifier) not switched select correct input on the
level display on or incorrectly adjusted amplifier
MASTER 1 displays Output not or incorrectly Connect output
a signal connected as described
In/output level incorrectly Adjust in/output level as
adjusted described
Buzzing tone can No earth connection Make earth connection
be heard between the devices between the devices via
the screw terminals
GND (40)
A cable is defective Replace cable
There is a buzzer loop Connect signal earth
between the connected through special earth-
devices insulated cable.
One channel does Connection cable has Check connection
not function become loose between devices
The balance control at the Set control BALANCE 1
mixer / amplifier is not (16) or balance control on
correctly adjusted the amplifier
Tone is distorted Channel fader (3) Set fader slide control as
incorrectly adjusted, described
the connected amplifier
is overloaded
Connected device does Use device with suitable
not adhere to the required connection
specification for a cinch or
XLR connection or does
not have the appropriate
connections
Control GAIN (24) Adjust control GAIN (24) as
incorrectly adjusted, described
the mixer is overloaded
Repairs other than those described above are only to be carried
out by an authorised specialist.
