28
Extractor hood 53 cm wide, with one or two motors:
Extractor hood 73 cm wide, with one or two motors:
Preparing the appliance
Exhaust-air mode
If the extractor hood is used in exhaust-air mode, a one-way
flap must be installed.
Note: The label or stamping on the one-way flap must face
outwards.
1. Click the two spigots on the one-way flap into place in the
holes on the air outlet and/or on the air inlet.
2. Check that the one-way flap is working correctly.
Air recirculation mode
If the extractor hood is used in circulating-air mode, the blow
opening must be secured using a circulated air grille. The
circulated air grille prevents mechanical and electrical hazards.
Rectangular air outlet
If the dust extractor hood has a rectangular air outlet, the air
inlet provided must be screwed in tightly via the air outlet.
PLQ
PLQ
PLQ
