WARNING
Do not use thin objects to
either clean or unblock
the injector.
✔ Put a cloth on the burner to protect
it from dirt.
✔ Loosen and remove the chimney.
✔ Remove the deflector unit.
✔ Clean and inspect the unit.
The deflector can have burn
powder and superficial corrosion.
The point, however, must be intact
and not corroded.
✔ Pass a brush over the chimney
tube. There should be no soot.
✔ Put the deflector unit back in
position, checking that the
deflector wire fits into the chimney
slots.
✔ Take the cloth off the burner and
put the protection hood back on.
✔ Test the operation of the
Refrigerator following the
instructions on pages 7 to 8.
Take off the protection hood and do
the following:
✔ Clean the openings and the burner
screen with a toothbrush.
✔ Clean and inspect the electrode and
thermocouple. If either is corroded,
have it changed. Check that they
are well attached and if necessary
tighten the screws.
✔ Check that the spark is created by
pressing the electric piezo ignite
button on the control panel.
CLEANING THE BURNER
CLEANING THE HEATER PIPE
ENGLISH
