Contractor CAB-110P - Page 21

ENGLISH
CONTRACOR
®
CAB-110P/CAB-135P Art. 15205/15206
21
Picture 6. Disposable
window replacement
ATTENTION!
Do not use plate glass for replacement view windows. It could shatter on
impact and cause severe injury.
Use only original manufacturer approved laminated safety glass.
Make sure the nozzle gasket is in place before screwing the nozzle into the nozzle holder
5.2.3 Disposable window replacement
Remove the two window frame nuts located on the upper edge of the window frame,
and swing the window frame open.
Through the door opening, push the disposable window from the back to remove from
the front.
Inspect the window frame gaskets, both on the window frame and on the cabinet. If
either gasket is damaged, replace it per section 5.2.5.
5.2.4 Viewing window replacement
Remove the two window frame nuts located on the upper edge of the window frame,
and swing the window frame open.
Remove the window to prevent breakage (Picture 7).
