Control 4 HC-200 User Manual

About this Document
Copyright©2011Control4.Control4,theControl4logo,the4-balllogo,theControl4Certied
logo, the Control4 iQ logo, and Everyday Easy are registered trademarks or trademarks of
Control4 Corporation in the United States and/or other countries. All other names or brands
may be claimed as property by their respective owners.
Part Number: 200-00183 Rev E 4/1/2011
Regulatory Compliance
FCC/Industry Canada
FCC ID: R33C4HC2001/Canadian IC : 7848A-C4HC200E
This device complies with Part 15 of the FCC Rules Sub-Part B and also with Canada ICES-
003 and RSS-Gen. Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation of this device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils
radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1)
l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le
fonctionnement.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Australian/New Zealand Compliance
• AS/NZS CISPR 22:2006 / A1:2007.
IMPORTANT! Anychangesormodicationsnotexpresslyapprovedbythe
party responsible for compliance could void the user’s authority to operate this
equipment.
IMPORTANT! Tousleschangementsoumodicationspasexpressément
approuvés par la partie responsable de la conformité ont pu vider l’autorité de
l’utilisateur pour actionner cet équipement.
Recycling
For information on recycling, please go to www.control4.com/recycling.
Limited Warranty
For complete warranty information, including details on consumer legal rights as well as
warranty exclusions, visit www.control4.com/warranty.
Set Up IR Emitters or IR Blaster
Your system may contain third-party products that are controlled with IR commands (usually
through remote controls). To provide a way for the Home Controller to control a device that
only recognizes IR commands, complete one of the following setups: IR Emitters or IR
Blaster.
IR Emitters
IR Blaster
In addition to IR emitters, the HC-200 is also equipped with an IR blaster, which is located
just left of the front LEDs. To use the blaster instead of an IR emitter:
Plug the 3.5 mm connector end of one of the 4 IR stick-on emitters provided into an IR
Out port on the HC-200.
Place the stick-on emitter end over the IR receiver on the Media Player, TV, or other
target device to drive IR signals from the HC-200 to the target.
1.
2.
In Composer, connect the Front IR Out of the Home Controller to the IR In of the device
you want to control.
Test and verify that the HC-200 is positioned in such a way that the blaster can reach
the device you want to control.
1.
2.
Set Up External Storage Device
You can store and access media from an external storage device, such as a network hard
driveorUSBmemorydevicebypluggingtheUSBdriveintotheUSBportandcongureor
scan the media from Composer.
Troubleshooting
Factory Restore Button
To restore the HC-200 for system recovery to the factory default image, on the bottom of
the device insert the end of a paper clip into the small hole.
Power cycle the device while pressing and holding the Factory Restore button for about
5-7 seconds and the Status LED blinks orange. This action starts the recovery process.
1.
2.
Identification Button
To reset the HC-200 to the network defaults, on the front of the device power cycle the
deviceandholdtheIdenticationbuttonuntiltheData,Link,andPowerLEDsaresolid
blue; immediately release the button.
Ifduringthebootsequence,theStatusLEDstaysOrange,pressandholdtheIdentica-
tion button until the LED blinks Blue, and then release it.
1.
2.

Control 4 HC-200 Specifications

General

Brand	Control 4
Model	HC-200
Category	Controller
Language	English
