Control Techniques UNI 1401 User Manual

13
drive technical specifications
Frequencies and
speed
PWM switching
frequency:
3kHz nominal (selectable
up to 12kHz)
Maximum speed
30 000 RPM
Speed regulation: 0.01%
Model Nominal Maximum total power dissipation
rating
@380V @460V 3kHz 4.5kHz 6kHz 9kHz 12kHz
UNI 1401 0.75kW 1.0HP 80 W 80 W 90 W 90 W 90 W
UNI 1402 1.1kW 1.5HP 90 W 90 W 100 W 100 W 110 W
UNI 1403 1.5kW 2.0HP 100 W 110 W 110 W 120 W 130 W
UNI 1404 2.2kW 3.0HP 130 W 130 W 140 W 150 W 150 W
UNI 1405 4.0kW 5.0HP 180 W 190 W 190 W 190 W 170 W
UNI 2401 5.5kW 7.5HP 210 W 230 W 250 W 280 W 310 W
UNI 2402 7.5kW 10HP 270 W 290 W 310 W 320 W 310 W
UNI 2403 11.0kW 15HP 400 W 380 W 360 W 330 W 310 W
UNI 3401 15.0kW 25HP 570 W 620 W 670 W 660 W 630 W
UNI 3402 18.5kW 30HP 660 W 720 W 730 W 660 W 630 W
UNI 3403 22.0kW 30HP 730 W 800 W 770 W 730 W 700 W
UNI 3404 30.0kW 40HP 950 W 830 W 790 W 740 W 710 W
UNI 3405 37.0kW 50HP 1090 W 990 W 920 W 850 W 800 W
UNI 4401 45kW 75HP 1460 W 1610 W 1630 W 1530 W
UNI 4402 55kW 100HP 1910 W 1780 W 1670 W 1560 W
UNI 4403 75kW 125HP 2370 W 2130 W 2030 W 1860 W
UNI 4404 90kW 150HP 2640 W 2890 W 2700 W 2470 W
UNI 4405 110kW 150HP 2970 W 2910 W 2720 W 2490 W
UNI 5401 160kW 200HP 5000 W
Dissipation
50°C (122°F) Maximum permissible
ambient continuous output current
Model 3kHz 4.5kHz 6kHz 9kHz 12kHz
UNI 1401 2.1 A 2.1 A 2.1 A 2.1 A 2.1 A
UNI 1402 2.8 A 2.8 A 2.8 A 2.8 A 2.8 A
UNI 1403 3.8 A 3.8 A 3.8 A 3.8 A 3.3 A
UNI 1404 5.6 A 5.6 A 5.1 A 4.0 A 3.3 A
UNI 1405 6.9 A 5.9 A 5.1 A 4.0 A 3.3 A
UNI 2401 12.0 A 12.0 A 12.0 A 11.6 A 9.7 A
UNI 2402 16.0 A 16.0 A 14.7 A 11.6 A 9.7 A
UNI 2403 20.0 A 17.3 A 14.7 A 11.6 A 9.7 A
UNI 3401 34.0 A 34.0 A 28.0 A 21.0 A 17.9 A
UNI 3402 40.0 A 34.0 A 28.0 A 21.0 A 17.9 A
UNI 3403 44.0 A 36.0 A 31.0 A 24.0 A 20.6 A
UNI 3404 44.0 A 36.0 A 31.0 A 24.0 A 20.9 A
UNI 3405 50.0 A 41.0 A 34.0 A 26.0 A 23.0 A
UNI 4401 95.0 A 85.0 A 75.0 A 60.0 A
UNI 4402 105.0 A 85.0 A 75.0 A 60.0 A
UNI 4403 135.0 A 105.0 A 85.0 A 65.0 A
UNI 4404 180.0 A 150.0 A 125.0 A 95.0 A
UNI 4405 190.0 A 150.0 A 125.0 A 95.0 A
