Control Techniques UNI 1404 User Manual

Model size 1
Model size 2
Model size 3
Model size 4
Panel
Panel
LFA
H
C
G
LFA
C
G
E
E
Panel
LF
A
C
G
E
E
H
C
E1
E1
Panel
E3
E2
L
FA
G
E2
E3
A 345 345 345 716
[13.56] [13.56] [13.56] [28.19]
C 47.5 95 187.5 250
[1.88] [3.75] [7.38] [9.81]
E 16.5 16.5
[.63] [.63]
E1 17
[.63]
E2 65
[2.56]
E3 143.5
[5.63]
F 368 368 368 743
[14.25] [14.25] [14.25] [29.25]
G 95 190 375 500
[3.75] [7.50] [14.75] [19.69]
H 200 200 260 260
[7.88] [7.88] [10.25] [10.25]
L 335 335 335 700
[13.19] [13.19] [13.19] [27.56]
Mounting 6.5 [ .16 ] clearance or
hole diam.
1
/
4
UNF M6 thread
Model Size 1 2 3 4
Dimension
➀
Surface Mounting
➀ Dimensions in mm and [inches].
drive installation
20
