drive installation
22
Model size kg lb
1 4 8.8
2817
32249
4 70 154
5 102 224
Weights
*Power Module only
*
Motor cable
Since capacitance in the motor cable causes loading
on the output of the Drive, ensure the cable length
does not exceed the values given in Table 2-3.
The maximum cable length is reduced from that
shown in the table under the following conditions:
● PWM switching frequency exceeding 3kHz in
model sizes 3 and 4
The maximum cable length is reduced in
proportion to the increase in PWM switching
frequency, eg. at 9kHz, the maximum length is
1/
3
of that shown.
● High capacitance cables
Most cables have an insulating jacket between
the cores and the armour or shield; these cables
have a low capacitance and are recommended.
Cables that do not have an insulating jacket
tend to have high capacitance; if a cable of this
type is used, the maximum cable length is half
that quoted in the table. (figure 2-1 shows
shows how to identify the two types.)
UNI1401 65 210 50 160
UNI1402 100 330 75 250
UNI1403 130 430 100 330
UNI1404 200 660 150 490
UNI1405 300 990 250 820
UNI2401- 300 990 300 990
UNI2403
UNI3401- 200 660 120 410
UNI3405
UNI4401- 200 660 120 410
UNI4405
mftmft
Model
Nominal AC
supply
voltage
400V
480V
Maximum cable length*
(PWM switching frequency at 3kHz)
* Cable lengths in excess of the specified values may be used only when
special techniques are adopted; refer to the supplier of the Drive.
Normal capacitance
Shield or armour
separated from the cores
High capacitance
Shield or armour
close to the cores
UNI1401 1.5 16 1.5 16 6
UNI1402 2.5 14 2.5 14 10
UNI1403 2.5 14 2.5 14 10
UNI1404 2.5 14 2.5 14 10
UNI1405 2.5 14 2.5 14 16
UNI2401 2.5 14 2.5 14 16
UNI2402 4.0 10 4.0 10 35
UNI2403 4.0 10 4.0 10 20
UNI3401 6 8 6 8 40
UNI3402 10 6 10 6 50
UNI3403 10 6 10 6 60
UNI3404 16 4 16 4 70
UNI3405 25 4 25 4 80
UNI4401 35 2 35 2 100
UNI4402 35 2 35 2 125
UNI4403 50 2/0 50 2/0 160
UNI4404 70 2/0 70 2/0 200
UNI4405 95 3/0 95 3/0 250
UNI5401 95 3/0 95 3/0 450
FUSES and CABLES
CATALOGUE
AC Supply Motor Fuse ➀
NUMBER
Cables Cables Rating
mm2 AWG mm2 AWG Amps
➀ Use Fuse class RK1 or similar HRC fuse.
➀
Cable & Fuse Recommendations
