CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
- 5 -
CONNECTOR INFORMATION
BATTERY +
DIGITAL INPUT 2
RS-485 +
RS-485 –
DIGITAL INPUT 3
GROUND
BATTERY +
CAN HIGH
CAN LOW
DIGITAL INPUT 1
FUEL LEVEL
GROUND
