Controls MVP-L3100 User Manual

CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
12
Configuration Menus
(2)
Input Configuration
Analog 1 Function
Digital Input Function
Digital B1 Function
Digital B2 Function
(3)
Output Configuration
Digital B2 Function (Default = Fuel/Run)
Digital B2 Polarity (Default = Positive)
Digital B2 Initial State (Default = On)
Digital B5 Function (Default = Preheat)
Digital B5 Polarity (Default = Positive)
Digital B5 Initial State (Default = Off)
Digital B6 Function (Default = None)
Digital B6 Polarity (Default = Positive)
Digital B6 Initial State (Default = Off)
(1)
Parameter Configuration
Parameter
Selection
Default Settings
Speed
Flywheel Teeth
30
Auto Set Teeth
No
Coolant Temp
Sender Type
S-W
Channel
Secondary Connector Pin 10
Oil Pressure
Sender Type
S-W
Channel
Secondary Connector Pin 2
Minimum Setting
0 PSI
Maximum Setting
100 PSI
Fuel Level
Fuel level Source
0-90 Ohm
Fuel Sender
S-W,
Fuel Channel
Primary Connector Pin 13
Voltage
Voltage Source
Battery –J1939
Battery Trim (Internal
Only)
Hour Meter
Hour Meter Source
Engine ECU
Set Hours (Internal
Only)
