CONTROL PANEL ANALOG AND DIGITAL INPUTS
The panel has one analog input and up to one digital input available to monitor other components,
senders or signals. These inputs can be used for a number of purposes including alarms and shut
downs.
Digital Outputs
1) Alarm – Engine shutdown when active with display message as assigned. A red lamp will also
be illuminated.
2) Pre Alarm – Warning message will be displayed along with a yellow lamp when active.
3) Pre Alarm & Alarm - Energizes an external audible alarm when a pre alarm or alarm condition
is present. Pressing the ENTER button will silence.
4) Alarm Horn - Energizes an external audible alarm when an alarm condition is present.
Pressing the ENTER button will silence.
5) Engine Run - Relay will be active when engine RPM is greater than 600. Typically used to
drive an auxiliary circuit such as louvers or send a signal to a monitoring station.
6) Low Oil Press Alarm - Relay closes if a low oil pressure shutdown is detected.
7) High Coolant Temp Alarm - Relay closes if a high engine temperature shutdown is detected.
8) Over Speed Alarm - Relay closes if an over speed shutdown is detected.
9) Over Crank Alarm - Relay closes if an over crank alarm is detected.
10) Low Fuel Level Alarm - Relay closes if a low fuel level shutdown is detected.
