19. TECHNICAL SPECIFICATIONS
HU-15OG
Transducer frequency 1,7 MHz
Maximum capacity 0-0,5 kg/hour (adjustable)
Service life of the transducers 10.000-20.000 hours
Size of the water droplets 1-3 micron
Diameter of outlet ange 1 x 40 mm
Diameter of suction ange 80 mm
Air ow adjustable (0-20 m
3
0 Pa)
Outlet pipe length 4 meter
Water pressure 1-6 bar
Water connection 3/4" external
Maximum water hardness 8º German hardness
(demineralised water
strongly recommended)
Flushing frequency 1x per hour (adjustable)
Water discharge 15 mm external
Content of water tank 100 cm
3
Mains voltage 230V ± 10% 50/60 Hz
Power consumption 60 W
Ambient temperature 0 °C - 35 °C
Water temperature 0 °C - 15 °C
Ambient temperature compared
to supply air temperature
Non condensing
Dimensions (LxWxH) 220 x 150 x 150 mm
Housing Stainless steel 316L
Weight 4 kg
Ozongenerator
Capacity ozone 20 mg/hour
Controlling ozone Via timer with day programming
