Convaid Cruiser 12 - Brake Assy with Attendant Brakes - Right

www.convaid.com42
Cruiser 12
Close-up
996008
QTYDESCRIPTIONPART NUMBERITEM
1
CX Parking Brake Assy (For Attendant Brakes) RH
5082351
1Rolko Foot Brake Lever Assy, RH5081462
2
Bolt 1/4"-28 x 1-3/4" Socket Button Hd Alloy Steel
1007513
1Locknut 1/4"-20 Jam Flexlock1001124
3
Nylon Washer 1/4" x 3/4" x 1/8"
1004785
3Coved Washer 3/4"1000656
5
Washer 7/16" AN-960-716
1000907
1Bolt 1/4"-20 x 3/4" Socket Button Head1004818
1
Bolt 1/4"-28 x 1-3/4" Socket Button head
1007519
4
Nylon Washer 1/4" x 11/16"10001310
3Washer 1/4" AN-960-41610008911
2
Locknut 1/4"-28 Flexlock Black Zinc
10004512
1Locknut 1/4"-20 Jam Flexlock10011213
1
Nylon Washer 1/4" x 1/2"
10002514
1Thread Locker-Medium-Vibra-tite10069015
Assembled
Exploded
Cruiser 10-12 Brakes w/Attendant Brakes RH
996007
QTYDESCRIPTIONPART NUMBERITEM
1
CX Parking Brake Assy (For Attendant Brakes) LH
5082341
1Rolko Foot Brake Lever Assy, LH5081452
2
Bolt 1/4"-28 x 1-3/4" Socket Button Hd Alloy Steel
1007513
1Locknut 1/4"-20 Jam Flexlock1001124
3
Nylon Washer 1/4" x 3/4" x 1/8"
1004785
3Coved Washer 3/4"1000656
5
Washer 7/16" AN-960-716
1000907
1Bolt 1/4"-20 x 3/4" Socket Button Head1004818
1
Bolt 1/4"-28 x 1-3/4" Socket Button head
1007519
4
Nylon Washer 1/4" x 11/16"10001310
3Washer 1/4" AN-960-41610008911
2
Locknut 1/4"-28 Flexlock Black Zinc
10004512
1Locknut 1/4"-20 Jam Flexlock10011213
1
Nylon Washer 1/4" x 1/2"
10002514
1Thread Locker-Medium-Vibra-tite10069015
415
11
12
14
1215
6
5
11
10
9
8
7
7
6
5
3
2
1
Axle Nut
Axle
Cruiser 10-12 Brakes w/Attendant Brakes LH
Assembled
Exploded
Rolko Attendant
Brake
Assembled
4
15
12
11
1
3
7
8
5
6
7
9
10
2
5
6
11
14
12 15
Axle Nut
Axle
Rolko Attendant
Brake
WHEELS
Brake Assy with Attendant Brakes - Right
Item Description Qty
1 CX Parking Brake Assembly (For Attendant Brakes), RH 1
2 Rolko Foot Brake Lever Assembly, RH 1
3 Bolt 1/4"-28 x 1-3/4" Socket Button Hd Alloy Steel 2
4 Locknut 1/4"-20 Jam Flexlock 1
5 Nylon Washer 1/4" x 3/4" x 1/8" 3
6 Coved Washer 3/4" 3
7 Washer 7/16" AN-960-716 5
8 Bolt 1/4"-20 x 3/4" Socket Button Head 1
9 Bolt 1/4"-28 x 1-3/4" Socket Button Head 1
10 Nylon Washer 1/4" x 11/16" 4
11 Washer 1/4" AN-960-416 3
12 Locknut 1/4"-28 Flexlock Black Zinc 2
13 Nylon Washer 1/4" x 1/2" 1
14 Thread Locker-Medium-Vibra-Tite 1
996008
#
Kit Includes
14
14
13
