Convair MASTERCOOL - Contents

2
CONTENTS
ASSEMBLY.....................................3-4
DIRECTIONSFORUSE.................4-6
MAINTENANCE..................................7
TROUBLESHOOTING........................8
EXPLODEDVIEW.........................9-10
WARRANTY......................................11
Caution-CheckVoltage
Toassemblethecooler
Howtogetthebestcooling
performance
Fillingwithwater
Usingthecooler- Lowfanspeed
Highfanspeed
Fanonly(vent)
Conditioningof Aspencoolingpads
Airdirectioncontrol
Safetyinstructions
Cleaningthecooler/rearpanel
removal
Todrainwater
Waterstrainerand Aspencoolingpad
Pumpbeltreplacement/DrainPlug
KEY (Figs4&5)
A Controls
B Frontgrille
C Waterfillingdoor
D Waterreservoir
E Castors
F Waterlevelindicator
G Frontpillar(Millenia,
Megacool)
H Base
I Rearpanelretaining
screws(2)
J Rearpanel
K Powercordentrypoint
L Reservoirdrainplug
M Ratinglabel
N Cordstoragehooks
O Rearpillar(Millenia,
Megacool)
B
D
C
E
H
F
G
A
ILL864-A
4
IL L 8 6 5 -B
K
L
J
I
N
M
O
5
