CAUTION! - Check Voltage
Before connecting your electrical power
cord to a power outlet, check that the cooler
voltage is the same as your power supply.
The cooler voltage will be stated on the
rating label at the rear of the cooler (Fig 6).
TOASSEMBLE THE COOLER
Push the four castors into their locating
holes in the base. Use a rotating motion to
assist in the entry of the steel spring ring
(“ ” Fig 7).
1
*
MODELSMILLENIA ANDMEGACOOL
ONLY
Assemble the front and rear pillars and
screw together. Place this assembly on the
base and slide into position until it locks (Fig
8).
IL L 8 6 6 -A
6
*
ILL867-B
7
ILL1221-A
8
ILL870-A
9
MODELSMILLENIA ANDMEGACOOL
ONLY
Place the reservoir of the cooler onto the
front pillar as shown (Fig 9). Tilt downwards
towards the rear until the
reservoir locks onto the rear pillar.
To remove the unit from the pillars, use a
screwdriver in the two recesses in the rear
of the reservoir to release the clips. Tilt the
unit forward to remove.
