Convotherm OEB 10.10 Service Manual

Service Handbook OEB/OES/OGB/OGS
AS/11-2011 0_01e_Table of Contents_d
Page 3 / 4
5. Trouble shooting List and Error Codes Electronic
5.1 Error Codes
5.2 General
5.3 Steam Generator
5.4 Condenser
5.5 Motor
5.6 Electronic
5.7 Safety temperature probe Convection heating (B7)
5.8 Error diagnosis with help of the LEDs on the Controls
(module self-checking)
6. Service Instructions
6.1 Electronic Control Board installation
6.1.1 Operation module (BM) replacement
6.1.2 Control Module (SM) replacement
6.1.3 Arrangement module replacement
6.1.4 Gas module (GM) removal
6.1.5 Description of the LEDs on the Controls (module self-checking)
6.2 Updating the Control and Operation module - Software
6.4 Steam Generator drain pump (only OEB and OGB)
6.5 Probe positions / Probe assembly and replacing
6.5.1 Safety thermostat above unit ceiling on table units
6.5.2 Safety thermostat behind the motor fastening on standing units
6.5.3 Probe with stuffing box assembly B10 (CTC)
6.5.4 Safety thermostat probe N8 on flange immersion heater
6.5.5 Double safety thermostats B8 and B7.2 in gas units with blower burner
6.5.6 Screw in probes B3, B4, B5 and oven probe B6
6.6 Water Level probe
6.7 Steam Generator-Immersion heater replacement (only OEB)
6.8 Motor / Fan Wheel installation and removal
6.9 Pressure Switch Cleaning System - Trouble Shooting

Convotherm OEB 10.10 Specifications

General

Model	OEB 10.10
Capacity	10 x 1/1 GN
Power Supply	Electric
Cooking Modes	Convection, Steam, Combination
Voltage	400 V
Frequency	50/60 Hz
Temperature Range	30°C to 300°C
