16
GB
IE
Getting started...
Built-in Fan-Assisted Oven by Cooke & Lewis
Installation
Fig. 1, Fig. 2: Installation distanced for simple electric ovens of 60 cm wide
(the shape of the upper casing may vary) and attachment to the cupboard.
A. The support runner must be removed
B. Spacing of 75-90 mm between the wall and the rear part of the
support shelf and the base of the cupboard
C. Base
D. False box front to be assembled
Fig. 2: Ventilation and gap requirements for the installation of a simple
electric oven in a standard cooking unit.
A
C
D
B
Fig.2
A110088_KSO_CLEF2SS-C_oven_v1_EN_FR_2011_12_12.indb 16 06/01/2012 5:14 PM
