Cooledge CTR-SCT-DMX-58V - Page 9

EXT-0087-R00-01082020 (LTR) 9/17
PSU 58V
100/200W
CH 1 & 2: 90W
CH 3 & 4: 90W
CH 1+
CH 1-
CH 2+
CH 2-
CH 3+
CH 4+
CH 3-
CH 4-
+VIN
GND
RED OR WHITE
BLACK
RED OR WHITE
BLACK
CH 1+
CH 1-
CH 2+
CH 2-
CH 3+
CH 4+
CH 3-
CH 4-
+VIN
GND
CH 3 & 4
CH 1 & 2
OUTPUT CONNECTIONS: TUNABLE WHITE (TNW)
Relevant Part No’s:
CTR-TNW-DMX-58V
CTR-DTW-DMX-58V
