Cooler Master GA2501 - Page 18

Supported Timing
16
PC Timing
HDMI IN VGA IN
640x480@60 Hz 31.469 59.940 25.175 o o
640x480@72 Hz 37.861 72.809 31.500 o o
640x480@75 Hz 37.500 75.000 31.500 o o
MAC 640x480@66 .66Hz 35.000 66.667 30.240 o o
VESA 720x400@70Hz 31.469 70.087 28.322 o o
800x600@56 Hz 35.156 56.250 36.000 o o
800x600@60 Hz 37.879 60.317 40.000 o o
800x600@72 Hz 48.077 72.188 50.000 o o
800x600@75 Hz 46.875 75.000 49.500 o o
MAC 832x624@74 .55Hz 49.722 74.550 57.280 o o
1024x768@60Hz 48.3 63 60.004 65.000 o o
1024x768@70Hz 56
.476 70.069 75.000 o o
1024x768@75Hz 60.0 23 75.029 78.750 o o
MAC 1152x870 @75Hz 68.681 75.062 100.000 o o
1152x864@75Hz 67.500 75.000 108.000 o o
1280x960@60Hz 60.000 60.000 108.000 o o
1280x1024@60Hz 63.981 60.020 108.000 o o
1280x1024@75Hz 79.976 75.025 135.000 o o
VESA
1280x720@60Hz 45.000 60.000 74.250
o o
WXGA
1280x800@60Hz 49.702 59.810 83.500
o o
WXGA+ 1440x900@60Hz 55.935 59.887 106.500 o o
WSXGA+ 1680x1050@60Hz 65.290 59.954 146.250 o o
1920x1080@60Hz 67.500
60.000 148.500 o o
1920×1080@75Hz 83.894 74.973 174.500 o o
1920x1080@100Hz 111.000 100.000 228.800 o ×
Port
Mode Resolution
Horizontal
Frequency
(KHz)
Vertical
Frequency
(Hz)
Pixel
Clock
(MHz)
VGA
SVGA
XGA
VESA
SXGA
UXGA
