Video Timing
Video
ID code
Formats
Aspect
Ratio
Field
Rate
(Hz)
Horizon
tal
(kHz)
Vertical
(Hz)
Pixel
Clock
(MHz)
H-Total
V-
Total
59.94 31.469 59.94 25.175 800 525
60 31.500 60.00 25.200 800 525
59.94 31.469 59.94 27.000 858 525
60 31.500 60.00 27.027 858 525
59.94 44.955 59.94 74.176 1650 750
60 45.000 60.00 74.250 1650 750
59.94 67.433 59.94 148.352 2200 1125
60 67.500 60.00 148.500 2200 1125
18 720x576p 16:9 50 31.250 50.00 27.000 864.000 625
19 1280x720p 16:9 50 37.500 50.00 74.250 1980.000 750
31 1920x1080
p
16:9 50 56.250 50.00 148.500 2640.000 1125
4 1280x720p 16:9
16 1920x1080
p
16:9
1 640x480p 4:3
3 720x480p 16:9
