Cooler Master TROOPER SE - Diagram; 示意图

02
Maximum height
for CPU cooler
1. CPU cooler installation:
Please ensure that your CPU cooler does NOT exceed 7.3 inch (186 mm) height, it will cause damage to the
side panel of the case and the CPU cooler.
Warning!!
186mm
Maximum length
for graphics card
2. Please ensure that your graphics card does NOT exceed 12.7 inch (322 mm) in length, it will cause
damage to the case and the graphics card.
Top-View / 顶-视图
Left side-View / 左侧-视图Front-View / 正-视图
Diagram / 示意图
USB 3.0
Audio
Reset
Power Switch
USB 2.0
Mic
322mm
