Cooline PT036 - Model Decoding

C : 1.5 HP ODP D : 2 HP ODP D : 2 HP ODP E : 3 HP ODP F : 3 HP TEFC G : 5 HP ODP H : 5 HP TEFC J : 7.5 HP ODP K : 7.5 HP TEFC J : 7.5 HP ODP K : 7.5 HP TEFC L : 10 HP ODP M : 10 HP TEFC L : 10 HP ODP M : 10 HP TEFC N : 15 HP ODP P : 15 HP TEFC
MODELS: PT075 - PT360 (BELT DRIVEN MOTOR)
1& 2
BASIC
3, 4 & 5
NOMINAL COOLING
CAPACITY
(MBH)
8
BLOWER
MOTOR
6
ELECTRICAL
SUPPLY
( V-Ph-Hz )
10
HEATER
OPTIONS
(kW/STAGE)
12
CONDENSER
COIL
PT
COOLINE
PACKAGED
UNIT
036 048 060
W : 0.75 HP ODP W : 0.75 HP ODP Y : 1 HP ODP
L : 380/415-3-50 (4 WIRE)
N : NO HEATER A : 5/1 B : 6/1 C : 7.5/1 D : 10 /2 E : 12/2
J : IGT + ENHANCED
AL. FINS
K : IGT + ENHANCED
MHG. FINS
L : IGT + CORRU-
GATED CU. FINS
9
DRIVE
OPTIONS
N : DIRECT
DRIVE
11
EVAPORATOR
COIL
J : IGT + ENHANCED
AL. FINS
K : IGT + ENHANCED
MHG. FINS
L : IGT + CORRU-
GATED CU. FINS
15
UNIT
ACCESSORIES
N : STANDARD UNIT C :FRESH AIR
MANUAL DAMPER
MODELS: PT036 - PT060 (DIRECT DRIVE MOTOR)
MODEL DECODING
7
REFRIGERA-
TION CIRCUIT
S : SINGLE
14
OTHER
OPTIONS
N : STANDARD UNIT I : ANTI-ICE U :UVM V : VOLT FREE
CONTACT
13
PDS
OPTION
N : NO PDS
OPTION
P : PDS OPTION
1& 2
BASIC
3, 4 & 5
NOMINAL COOLING
CAPACITY
(MBH)
8
BLOWER
MOTOR
6
ELECTRICAL
SUPPLY
( V-Ph-Hz )
10
HEATER
OPTIONS
(kW/STAGE)
12
CONDENSER
COIL
PT
COOLINE
PACKAGED
UNIT
075 090 100
120***
180 215 240 300 360
L : 380/415-3-50 (4 WIRE)
N : NO HEATER A : 5/1* B : 6/1* C : 7.5/1 D : 10 /2 E : 12/2 F : 15 /2 G : 20 /2 C : 7.5/1 D : 10 /2 E : 12/2 F : 15 /2 G : 20 /2 H : 25/2 J : 30/2**
J : IGT + ENHANCED
AL. FINS
K : IGT + ENHANCED
MHG. FINS
L : IGT + CORRU-
GATED CU. FINS
9
DRIVE
OPTIONS
J : ALT. I K : ALT. II
11
EVAPORATOR
COIL
J : IGT + ENHANCED
AL. FINS
K : IGT + ENHANCED
MHG. FINS
L : IGT + CORRU-
GATED CU. FINS
15
UNIT
ACCESSORIES
N : STANDARD UNIT C :FRESH AIR
MANUAL DAMPER
7
REFRIGERA-
TION CIRCUIT
S : SINGLE
14
OTHER
OPTIONS
N : STANDARD UNIT I : ANTI-ICE U :UVM V : VOLT FREE
CONTACT
13
PDS
OPTION
N : NO PDS
OPTION
P : PDS OPTION
NOTE:
*
– Applicable for PT075 models only.
**
– Applicable for models PT180 & above only.
***
– 3 HP motor only available for PT120.
D :DUAL
