Permanent installation
1. Drill an appropriately big hole in the outer wall. It should be maximum 120 cm and minimum 30 cm from the floor.
2. Now fix Adapter A with the help of four expansion plugs and screws.
3. Fix the loose end of the exhaust hose (which you used earlier in the appliance – see above) on Adapter A.
4. You can cover the opening in the wall with the adapter cap when you do not want to use the appliance.
5. The cable can be compressed or stretched in the 50 cm to 200 cm range. The appliance works more effectively when the
cable length is maintained as short as possible.
NOTE
Do not bend the cable sharply.
