1. To ensure optimal performance of the appliance, the warm air must be guided out of the room.
2. To do this, move the exhaust air hose as illustrated in the figure, with one end over the hot air outlet.
3. There are two options of transporting the hot air in the outward direction:
Temporary installation
Mount Adapter B at the loose end of the exhaust air hose
1. You can now simply let it hang out of the window, which must be closed as far as possible to prevent hot air from
returning to the room or to prevent fresh hot air from outside from entering the room.
2. Or you can use the attached window panel set. In most cases, this set can be applied vertically or horizontally to the
closing standard window. The panel is pushed to the required length and “clamped” to the window frame while closing
the window. You can introduce Adapter B in the hole in the panel.
INSTALLATION
2
Window panel set minimum: 67.5 cm (2.22ft)/ maximum: 123 cm (4.04ft).
If the window opening is smaller than the specified minimum length of the window panel, please shorten one side of
the panel so that it can be inserted. Do not shorten the side of the panel in which the hole is located.
