This document is intended for installers of the WaveLinx Lite
System
DISCLAIMER OF LIABILITY: Cooper Lighting Solutions assumes no liability for damages or losses of any kind that may arise from the
improper, careless, or negligent installation, handling or use of the products.
IMPORTANT: This manual provides information on the installation and operation of WaveLinx Lite System. For proper operation it is
important to follow the installation instructions for each product/component.
NOTE: WaveLinx Lite devices are not currently compatible with the WaveLinx Wireless Area Controller.
ATTENTION
User and Programming Manual
WaveLinx Lite

Table of Contents

Questions and Answers

  • N
    Nathan GordonAug 1, 2025
    How to fix the communications icon indicating no network connection on Cooper Lighting Equipment?
    • C
      Carolyn RichardsonAug 1, 2025
      If the communications icon indicates no network connection on your Cooper Lighting Equipment, try the following: * Tap the icon to refresh the connection. * Ensure Bluetooth is turned on. * Verify devices are provisioned and assigned to the area. * Reset the Bluetooth connection by turning it off and on again. * Move closer to the nearest WaveLinx Lite Device.
  • B
    birdjosephAug 6, 2025
    What to do if there are alert icons on the zone and/or devices of Cooper Lighting Lighting Equipment?
    • L
      Lindsey SmithAug 6, 2025
      Alert icons on the zone or devices of your Cooper Lighting Equipment indicate that programmed settings failed to transmit completely. Ensure your mobile device is within range of the nearest WaveLinx Lite device and that the network shows a connection. First, process the zone alert by tapping the alert icon at the top of the zone screen to reprocess communications. If successful, the alert will clear, and device alerts may clear too. Retry if needed. If device alerts persist, tap the device alert to reprocess communication. The alert will clear once settings are sent. Retry if needed. Clear zone alert first, then device alert.
  • D
    Darren CooperAug 10, 2025
    Why does Cooper Lighting Equipment display an ‘Area Disconnected’ message?
    • V
      Veronica ParkerAug 10, 2025
      An ‘Area Disconnected’ message on your Cooper Lighting Equipment typically appears after communications have completed, which may reset the device. The network connection should refresh automatically. If it doesn't, tap the icon. Also, ensure Bluetooth is on and move closer to one of the devices if the network fails to connect, as the mobile device might be out of range.
  • H
    Heather BurnsAug 14, 2025
    What to do if Cooper Lighting Equipment device appears to be offline?
    • C
      Cynthia SmithSep 12, 2025
      If your Cooper Lighting Equipment device appears offline and attempts to send settings fail, first verify the device has power and check for LED activity in response to motion. If power is confirmed, bring the mobile device close to the WaveLinx Lite device and try a ‘blink to identify’ command via the mobile application. If the device responds, attempt to communicate again. If communication still fails, the device may need to be deleted and reprovisioned. If the device does not respond, no answer.
  • A
    adamschristineAug 18, 2025
    Why does Cooper Lighting Lighting Equipment say ‘This warning cannot be resolved’?
    • M
      Margaret TurnerAug 19, 2025
      If you see the message ‘This warning cannot be resolved. Please resolve the zone warning’ on your Cooper Lighting Equipment, it means you need to clear the zone alert before clearing the device alert. Always clear alerts at the zone level before addressing device-level alerts.
  • A
    Allison DavisAug 22, 2025
    How to fix Cooper Lighting Lighting Equipment device working differently after adjustments?
    • A
      Alex FieldsAug 23, 2025
      If a Cooper Lighting Equipment device is working differently after occupancy set or scene level adjustments, ensure all devices are powered and online. Use the mobile application to change a setting in the occupancy set or scene level, save the change, and then change the setting back to the desired selection and save it again. This will refresh the setting to all communicating devices.
  • N
    Nicole WalkerAug 27, 2025
    What does it mean when Cooper Lighting Equipment displays 'RSSI is too low'?
    • J
      Jesse MaynardAug 27, 2025
      A 'RSSI is too low' message on your Cooper Lighting Equipment indicates a weak Bluetooth signal during provisioning or firmware updates. Move as close as possible to the WaveLinx Lite Device, ensuring you are within 60 feet including the fixture height.

Summary

Logging in to the WaveLinx Lite Mobile Application

Step 1: Download and install the WaveLinx Lite Mobile Application

Guides users on downloading and installing the mobile application on iOS or Android devices.

Step 2: Register for WaveLinx Lite Mobile Application Access

Step 3: Login to the Mobile Application

Initial Site Setup Using the Mobile Application

Step 1: Create a Site

Guides on creating a new site, including essential details and naming conventions.

Step 2: Create Areas

Step 3: Provision an Areas First Device

Step 4: Manage the Area Zones

Step 5: Manage the Area Occupancy Sets

Part 1: Create New Occupancy Sets

Details the process of creating additional occupancy sets for specific zone control.

Part 2: Assign and Unassign Zones to Occupancy Sets

Step 6: Provision Remaining Area Devices and Assign to Zones

Step 7: Repeat the Process for Additional Areas

Modify Default Behavior After Provisioning

Modify Zones

Modify Devices

Delete Devices (Return to Unprovisioned State)

Modify Occupancy Sets

Adjust Individual Occupancy Sensor Settings

Adjust Occupancy Set Settings

Modify Wallstations

Modify Wallstation Actions

Modify Scene Light Levels

Calibrate Daylight Sets

Calibrate Closed Loop Daylight Sensors

Calibrating All Sensors in an Area

Use Screen Controls to Issue Commands and View Details

Issue Scene Commands

Perform Administrative Functions

Reset a Site Administrator Password

Guides on resetting a site administrator password using the mobile application.

Edit Site Details

Perform a Site Backup (Sync)

Restore a Site

Transfer Site Ownership

Update Device Firmware

Obtain Firmware File

Run Device Update

Details the steps for performing a firmware update on a WaveLinx Lite device.

Update the Mobile Application

Basic Troubleshooting

Resolve Mobile Application Communication Issues

Offers specific steps to troubleshoot network and Bluetooth connection problems.

Replace Devices

Factory Reset a Device

Advanced Daylight Calibration: Calculate the Daylighting Factor Sensitivity Value

Cooper Lighting WaveLinx Lite Specifications

General IconGeneral
Product TypeLighting Control System
CategoryLighting Equipment
TypeWireless Lighting Control
Power Supply120-277V AC
Frequency2.4 GHz
Power Factor>0.9
Mobile App CompatibilityiOS, Android
CertificationsUL, FCC, CE
Control MethodApp
System ComponentsSensors, Gateways
Control CapabilitiesDimming, Scheduling
SecurityAES Encryption
Humidity0-95% non-condensing
Communication ProtocolWaveLinx Wireless
Wireless ProtocolIEEE 802.15.4
Dimming0-10V, Phase Dimming
