Copal PS30 User Manual

7
OutlineDimensions（Unit:mm）
Ifusingthepanelholderset（soldseparately）,installthemainbodytothepanelfolder,andholdthemainbodybytwopanelstopperthroughtheattachment
panel.
PanelHolderSet（Option）
PS30
PortBlock（soldseparately）
Panelholdercover
Panelholder
Mainbody（PS30）
Attachmentpanel
Panelstopper
（two）
Holder
coverset
Panel
holderset
36
＋0.5
0
36
＋0.5
0
panelcutdimentions
（Panelthickness:1〜3.6mm）
■Accessories（Soldseparately）
Productname Modelno. Description
Applicable
model
Angledbracket
forwallattachment
Angledbracket
forfloodattachment
Panelholderset
Holdercoverset
（forprotectionof
gaugesides）
ACPG-001
Angledbracketforwall
attachment,twoM3×4
malescrews
Angledbracketforfloor
attachment,twoM3×4
malescrews
Panelholdercover,
panelholder,two
panelstoppers
Panelholdercover,
panelholder
ACPG-002
ACPG-003
ACPG-004
Portbrockset
Portblock
O-ring（P8）
M3×10malescrew（twopieces）
Sealingscrew
ACPG-005
PG-30
/PS30
PG-30
/PS30
PG-30
/PG-35
/PS30
PG-30
/PG-35
/PS30
PS30
□31
□30
20
29
20
O-ringgroove
（P8）
4
Case
ABS
Base
ABS
Pressureport
M5,effectivedepth5
2−M3
Effectivedepth6
4-corecable(φ4)
Length1500±100（UL2844）
Mainbody
(PS30)
□31
20
15
10
20
Pressureport
2−Rc1/8
4−φ3.3
