Copal PS30 User Manual

6
Adjustingzeropoint
Exitingzeropointadjustment
ZeroPointAdjustment
Adjustthepressureindicationatthetimeofpressurereleaseinthepressureportto"zero".
Piping
PipingandInstallation
Holdthebasesectionofthemainbodytoconnectacommerciallyavailablefitting（M5malescrew）tothemainbody.Tightenwithatorqueof１.０N・morless.
（Note）Donotapplyanyforceonthecoversectionofthemainbodyduringtightening.Theswitchunitmaybreak.
Backmountingscrews
Themainbodycanbesecuredtothepanelbyusingthemountingscrewholeslocatedontheback（2−M3,effectivedepth:6mm）.Toinstall,holdtheuniton
thebasesectionwhentighteningthescrews.Useatighteningtorqueof0.3N・morless.
（Note）Donotapplyanyforceonthecoversectionofthemainbodyduringtightening.Theswitchunitmaybreak.
AngledBrackets（Option）
PortBlock(soldseparately)
If using the port block（sold separately）, put the O-ring（P8）in the O-ring groove located on the
backofthemainbodyasshowninthefigurebelow,andinstalltheportblockbytwoM3×10male
screws.When installing, hold the basesection of themain body, then tighten themale screws.
Useatighteningtorqueof0.3N・morless.
Whenconnectafittingtotheportblock,windsealingtapearoundthepipetopreventairleakage.
Theother pressure portwhich are not to be used should bestopped up withthe sealing screw
provided.Inthiscase,windsealingtapearoundthescrewsbeforeusing.Anyfirstlytightenthescrewsusing
fingerstoavoiddamagetothescrewthreads.Finally,tightenfirmlywithawrench.(Recommendedtorque:3.0N・m)
Forpipingwork,securetheportblockusinga12mmwrench.Useatighteningtorqueof10.0N・morless.
（Note）Donotapplyanyforcetothecoversectionofthemainbodyduringtightening.Theswitchunitmaybreak.
Ifusingtheangledbracketforwallattachment（soldseparately）ortheanglebracketforfloorattachment（soldseparately）,installtheangledbracketbytwoM3×4
malescrewsasshowninthefigurebelow.
Ifusingtheangledbracketandtheportblock,installboththeangledbracketandtheportblockbytwoM3×10malescrews.
Wheninstalling,holdthebasesectionofthemainbody,thentightenthemalescrews.Useatighteningtorqueof0.3N・morless.
（Note）Donotapplyanyforcetothecoversectionofthemainbodyduringtightening.Theswitchunitmaybreak.
Releasetheappliedpressureinthepressureport
（i.e.,letthepressureportbeopenedtotheatmosphere）.
Pressthe and buttonssimultaneouslyinOperationsMode.
Thevalue willblinkwhenyouenterthezeropointadjustmentphase.
▼ ▲
PS30SW1
kPaSW2
M
Withthevalue flashing,release and
buttonssimultaneously.
Onesecondlaterzeropointadjustmentwillbemade
andyouwillreturntoOperationsMode.
▼
▲
Ifpressureisappliedduringzeropointadjustment,
willbedisplayed.
Pressthe buttonmorethanonesecondtoreset
the display.
Releasetheappliedpressureonthepressureport
（openedtotheatmosphere）,thenperformzeropoint
adjustmentagain.
PS30SW1
kPaSW2
PS30SW1
kPaSW2
Mainbody（PS30）
O-ring（P8）
Portblock
M3×1 0
malescrew
（twopieces）
Mainbody（PS30） Mainbody（PS30）
Angledbracket
forwallattachment
Angledbracket
forfloorattachment
M3×4
malescrew
（twopieces）
M3×4
malescrew
（twopieces）
