ATTACHING THE TRAILER TO BIKE
Remove rear wheel bolt. Attach quick release mounting bolt to the wheel. Re-tighten
rear wheel bolt. Attach quick release pin to the trailer arm and latch securely. Figure
8A, 8B and 8C.
CONVERSION KIT ASSEMBLY
The conversion kit consists of a rear handle and front
wheel assembly that attach to the trailer to convert it
for walking use.
The front wheel attaches to the hitch arm assembly
using a simple clamp that is designed to attach in only
one manner. Line up the tabs on the clamp with the
corresponding holes in the hitch arm – tighten.
Figure 9A.
The handle bar attaches to the rear side support frame
uprights with clamps. Loosen the knobs, slide the
clamps through the portholes provided in the fabric,
around the frame and tighten. Tug on the handle bar
to make certain that it is tight on the frame. Figure 9B.
Remove the conversion kit wheel and handle bar before towing the trailer. The wheel
can catch on the ground and the handle bar can hook onto things unexpectedly
while turning.
8A
9A
8B
9B
8C
