TABLE OF CONTENTS
PAGE
SAFETY CONSIDERATIONS 1................................
INTRODUCTION 2..........................................
INSTALLATION CONSIDERATIONS 3..........................
INSTALLATION 6...........................................
SYSTEM START−UP AND CHECKOUT 43......................
OPERATIONAL INFORMATION 52............................
TROUBLESHOOTING 56.....................................
LIST OF WIRING DIAGRAMS 60..............................
WIRING DIAGRAMS 61−76...................................
SAFETY CONSIDERATIONS
Read and follow manufacturer instructions carefully. Follow all local electrical
codes during installation. All wiring must conform to local and national electrical
codes. Improper wiring or installation may damage Thermostat.
Recognize safety information. This is the safety−alert symbol . When you see
this symbol on the equipment and in the instruction manual, be alert to the potential
for personal injury.
Understand the signal words DANGER, WARNING, and CAUTION. These
words are used with the safety−alert symbol. DANGER identifies the most serious
hazards which will result in severe personal injury or death. WARNING signifies a
hazard which could result in personal injury or death. CAUTION is used to identify
unsafe practices which may result in minor personal injury or product and property
damage. NOTE is used to highlight suggestions which will result in enhanced
installation, reliability, or operation.
