cor thermostat 7C - Single−Stage Furnace with Single−Speed Air Conditioner

72
Y
G
W
C
Y
C
Furnace
Single-Stage
Air Condioner
* Indicates connecon may not be required/available
O/W2/B
G
Y1/W2
Y/Y2
Rc/V+
Rh
C/Vg
W/W1
HUM*
N/A
Fan
N/A
Cool Stage 1
24VAC Hot Cooling
24VAC Hot Heang
24VAC Common
Heat Stage 1
Humidify
R R*
Côr 5, Côr 5C, Côr 7, or Côr 7C Thermostat
Humidifier Solenoid
Valve*
Fig. 20 − Single−Stage Furnace with Single−Speed Air Conditioner
