51
GB
Assembly Chart 1210/1201
shelves
6
Using a Phillips screwdriver, screw the Maxifix
bolts (part 8) into the insert nuts (part 10) in
the shelf (part 3).
7
Now connect the shelves (parts 3 + 5). To do
so, plug the two boards together as shown in
the illustration and then tighten the Maxifix
housings (part 9) using an Allen key.
