WARNING: Ensuring
Adequate Ventilation
Make sure the induction cooker hob is well ventilated and that air inlet and outlet are not
blocked.
In
order to avoid accidental touch with the overheating bottom of the hob, or getting unexpectable
electric shock during working, it is necessary to put a wooden insert, fixed by screws, at a minimum
distance of 50mm from the bottom of the hob. Follow the requirements below.
There are ventilation holes around outside of the hob. YOU MUST ensure these holes
are not blocked by the worktop when you put the hob into position.
Be aware that the glue that join the plastic or wooden material to the furniture,
has to resist to temperature not below 150℃, to avoid the unstuck of the
paneling.
The rear wall, adjacent and surrounding surfaces must therefore be able to
withstand an temperature of 90℃.
A(mm)
B(mm)
C(mm)
D
E
760 50 min. 20 min. Air intake Air exit 5mm
