50
Minimum height of lift 110 mm
Length of the lift 1450 mm
Width of the lift 1920 mm
Width of platforms 560 mm
Free width between platforms 800 mm
Lifting time 20 s
Lowering time 20 s
Noise level 70 dB(A)/1m
Total weight of the lift 850 Kgp
Working temperature
-10 °C 40 °C
Compressed air pressure -NP-
5.2 ELECTRIC MOTOR
Type 90LA/4
Power 3 KW
Voltage 230 V / 400V
Frequency 50 Hz
N° Poles 4
Speed 1380 giri/min
Motor enclosure type Flangia Quadra
Insulation class IP 54
Amperage
14,7
A a 230 V
8,5 A a 400 V
Motor connection must be carried out referring to the attached wiring diagrams (Ref. FIG. 7).
The motor direction of rotation is shown in the label placed on the motor.
If not specifically required, the lift is supplied with three phases motor (400 V).
5.3 PUMP
Type gear AP100/5
Flow rate 5 cm3/g 3Hp , 3,5 cm3/g 1 Hp
Continuous working pressure 210 bar (3000 psi)
Intermittent working pressure 230 bar (3300 psi)
Peak pressure 280 bar (4000 psi)
5 CHAPTER 5 - TECHNICAL SPECIFICATION
5.1
SIZE AND MAIN FEATURES (Rif. Figure 4)
Capacity 3000 Kgp ( 29400N)
Maximum lifting capacity 970 mm
