5 92059OPR
REMOVAL AND REPLACEMENT OF AGITATORS
LEFT HAND
AGITATOR
O–RING
FRONT (VALVE SIDE) VIEW FROM TOP OF DISPENSER
RIGHT HAND AGITATOR
WITH HOLE IN UPRIGHT
COUNTER CLOCKWISE
CLOCKWISE
ROTATION ROTATION
To Remove Agitators For Cleaning
1. Lift agitator and disc from unit..
2. Remove O-Ring starting at notch. Warm the O-Ring with water to ease removal.
3. Lift the plastic agitator disc off of the stainless-steel agitator.
4. Replace by reversing steps.
Note: Refer to Sanitize Procedure in the Owners Instruction for complete cleaning and sanitizing
instructions.
