STANDARD RECOMMENDED PROCEDURE 003-895 | ISSUE 4 | OCTOBER 2017 | PAGE 8 OF 12
4.3 Splicing Tight Buffer or Loose Tube Fiber
Cut to:
120 cm (48 inches) - 250 micron
90 cm (35 inches) - 900 micron
1
2
3
TPA-3933
Strain-relieve to
end of incoming
cable.
5
6
4
TPA-3934
Repeat Step 5
on the other side of
cassette. Loop
and store all fiber
under flanges.
Fold fiber over
into cassette
and store under
flanges.
Cover
7
8
9
TPA-3935
Close cover.
Replace cover.
