CORNING CCH-CS - Splice Cassette (CCH-CS) Installation - Tight Buffer or Loose Tube Fiber

STANDARD RECOMMENDED PROCEDURE 003-895 | ISSUE 4 | OCTOBER 2017 | PAGE 6 OF 12
4. Splice Cassette (CCH-CS) Installation — Tight Buffer or Loose
Tube Fiber
4.1 Fiber Routing
NOTE: Be sure not to pinch bers when installing the tray
1
2
TPA-3928
TPA-3929
3
70 cm
27 inches
4
TPA-3930
5
Total Length:
NOTE: If using pigtail panels, remove the MIC
jacketing from the cable rst.
