8
Antennas
The radio node includes four internal Tx/Rx antennas with a peak gain of 5dBi and operates in 2x2 mode with
MIMO or two optional ports with QMA coaxial connectors for external antennas. Both models contain one
internal network listen antenna. Figure 4 shows the location of the LTE antennas:
Figure 4 Antenna Band Locations
Figure 5 shows the radio node with external antennas. This view is oriented the same way as Figure 4, so the
antenna locations are the same.
Figure 5 External Antenna Connectors
Band 2
Tx1
Band 2
Tx2
Band 1
Tx2
Band 1
Tx1
Internal
Sniffer
Antenna
