VERSIONS AND MOTORISATIONS
220 volt / 218 watt motor reducer complete with limit switch.
Required for 2, 3 or 4 runner awning, flat version, where the awning
remains slack, or for the taut, tilted version, with a maximum projection
of 350 cm.
ELECTRIC DRIVE TYPE 1
PLAN motor
WIDTH
PROJECTION
WALL BEAM HEIGHT
PILLAR
1
2
4
3
EXYL 2 RUNNERS
EXYL 3 RUNNERS
EXYL 4 RUNNERS
2 - 04.2011
CORRADI S.P.A. - USER MANUAL - EXYL
26 of 109
