Appendix 3 – Hookup (trigger to cameras)
With ATB-5
Direct connection
ATB-5
Trigger box
BNC cable to trigger output
Trigger to camera
(CSI trigger cables)
BNC cable to trigger output
Trigger to camera
(Manufacturer BNC to trigger cables)
BNC Tee
