Corsair 460X - Component Installation; Installing Power Supply; Installing Expansion Cards; Front Panel Connections

CRYSTAL SERIES 460X
8. Installing the Front I/O Connectors
7. Removing the Front Fascia
6. Installing PCI-E/PCI Card(s)
5. Installing the Power Supply
1. Remove thumbscrews and
corresponding slot covers.
2. Install the expansion
card and secure with
thumbscrews.
Unscrew the front panel, then
gently but firmly pull away from
the chassis.
Install the PSU into the
lower chamber of the case,
and secure with four screws
from behind.
400C_400Q STEP 6
1
400C_400Q STEP 6
2
USB 3.0
HD AUDIO RESET SW
POWER LED +
POWER LED –POWER SW
HDD LED
See your motherboard’s
manual for front panel header
locations and pin-outs.
