Corsair 460X User Manual

CRYSTAL SERIES 460X
13
Frequently Asked Questions9. Using RGB Fan Controller (460X - RGB)
1. Does the polarity matter with the I/O panel’s power
and reset header?
No, only the LED headers.
2.
Where can I mount a fan?
Fan Mount Locations
Front 3x120mm, 2x140mm
Top 2x140mm/120mm
Rear 120mm
Bottom x
Side x
Mid x
See included RGB Fan controller
Quick Start Guide for detailed instructions.

Corsair 460X Specifications

General

Motherboard Support	ATX, Micro-ATX, Mini-ITX
Dimensions	440mm x 220mm x 464mm
Material	Steel, Tempered Glass
Expansion Slots	7
Cooling Support	Front: 3 x 120mm or 2 x 140mm, Top: 2 x 120mm or 2 x 140mm, Rear: 1 x 120mm
Radiator Compatibility	Front: 360mm, Top: 240mm, Rear: 120mm
Maximum GPU Length	370mm
Maximum CPU Cooler Height	170mm
Maximum PSU Length	200mm
Type	Mid-Tower
Drive Bays	2 x 3.5", 3 x 2.5"
Pre-installed Fans	3 x 120mm RGB LED
I/O Ports	2 x USB 3.0, 1 x Headphone, 1 x Microphone
