General| Efficiency | 92 % |
|---|---|
| Total power | 860 W |
| Power factor | 0.99 |
| Input current | 6 - 12 A |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Combined power (+12V) | 859.2 W |
| Combined power (-12V) | 9.6 W |
| Combined power (+3.3V) | 125 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+12V) | 71.6 A |
| Max output current (-12V) | 0.8 A |
| Power protection features | Over current, Over voltage, Short circuit, Under voltage |
| Max output current (+3.3V) | 25 A |
| Max output current (+5Vsb) | 3 A |
| Maximum input current (@110V) | +12V, +3.3V, +5V, +5Vsb, -12V A |
| Power Factor Correction (PFC) type | Active |
| Fan diameter | 120 mm |
| On/off switch | Yes |
| Product color | Black |
| Number of fans | 1 fan(s) |
| Cabling type | Fully-Modular |
| Motherboard power connector | 24-pin ATX |
| Floppy drive power connector | 2 |
| Number of SATA power connectors | 12 |
| PCI Express power connectors (6+2 pin) | 6 |
| Peripheral (Molex) power connectors (4-pin) | 8 |
| Purpose | PC |
| ATX version | 2.31 |
| EPS version | 2.92 |
| Noise level | 28.7 dB |
| Certification | cTUVs, TUV, CB, CE, FCC, CCC, RCM, GOST-R, KC, IRAM, BSMI |
| 80 PLUS certification | 80 PLUS Platinum |
| Mean time between failures (MTBF) | 100000 h |
| Power supply unit (PSU) form factor | ATX |
| Package weight | 4000 g |
Weight and Dimensions| Depth | 160 mm |
|---|---|
| Width | 150 mm |
| Height | 86 mm |
| Weight | 3290 g |
