Corsair ONE User Manual


SETTING UP CORSAIR ONE

SERVICE
> Introduction ...................................................................................................1
> CORSAIR ONE Contents .......................................................................... 2
> Front Ports .................................................................................................... 3
> Rear Ports ...................................................................................................... 3
> Installing Wireless Antennas .................................................................. 
> Connecting Power Cable .........................................................................4
> Connecting Keyboard and Mouse ........................................................ 5
> Connecting Monitor(s) .............................................................................. 5
> Connecting Speakers (optional) ...........................................................6
> Connecting Networks (optional) .......................................................... 7
> Connecting VR Headset (optional) ...................................................... 7
> Updating Drivers and Software ............................................................ 8
> Upgrading CORSAIR ONE .......................................................................8
> FAQ and Troubleshooting .......................................................................9
> Warranty Information ............................................................................. 10
TABLE OF CONTENTS

Corsair ONE Specifications

General

Bus type	DMI3
Stepping	B0
Tjunction	100 °C
Processor cache	8 MB
Processor cores	4
Processor model	i7-7700
System bus rate	8 GT/s
Processor family	Intel® Core™ i7
Processor socket	LGA 1151 (Socket H4)
Processor threads	8
Processor codename	Kaby Lake
Processor frequency	3.6 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	4.2 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 1x8+2x4, 2x8
Thermal Design Power (TDP)	65 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
Memory clock speeds supported by processor	1333, 1600, 2133, 2400 MHz
Maximum internal memory supported by processor	64 GB
Scalability	1S
Processor code	SR338
Processor ARK ID	97128
Processor package size	37.5 x 37.5 mm
Conflict-Free processor	Yes
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2015C
Intel Identity Protection Technology version	1.00
Internal memory	16 GB
Memory channels	Dual-channel
Memory clock speed	2400 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	- GB
HDD capacity	1000 GB
SSD capacity	240 GB
HDD interface	SATA
Storage media	HDD+SSD
Card reader integrated	-
Total storage capacity	1240 GB
On-board graphics card ID	0x5912
Discrete graphics card model	NVIDIA® GeForce® GTX 1070
On-board graphics card model	Intel® HD Graphics 630
Discrete graphics memory type	GDDR5
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Number of displays supported (on-board graphics)	3
Wi-Fi standards	Wi-Fi 5 (802.11ac)
USB 2.0 ports quantity	2
Chassis type	Midi Tower
Product color	Black
Housing material	Steel
Product type	PC
Motherboard chipset	Intel® Z270
Power supply	400 W

Weight and Dimensions

Depth	176 mm
Width	200 mm
Height	380 mm
Weight	7200 g
