Corsair RM1000e User Manual

ENGLISHENGLISH
TABLE OF CONTENTS
CORSAIR RMe Series fully modular power supplies deliver reliable 80 PLUS Gold efficient power to your system.
CONGRATULATIONS ON THE PURCHASE OF YOUR
NEW CORSAIR RMe SERIES ATX POWER SUPPLY!
SAFETY AND PROTECTION
• Over-Voltage Protection (OVP)
Over-voltage protection for the 12V, 5V, and 3.3V DC outputs is required to comply with the ATX specification.
OVP shuts down the PSU in the event that the DC outputs exceed a set level, determined by the PSU
manufacturer.
• Over-Current Protection (OCP)
OCP is featured on the 3.3V, 5V, and 12V rails. OCP ensures that the output of the DC voltage rails remains within
safe operating limits.
• Over-Temperature Protection (OTP)
OTP ensures that the PSU will shut down when the internal temperature reaches a set point. This is usually as a
result of internal current overloading or a fan failure.
• Short-Circuit Protection (SCP)
A short-circuit is defined as any output impedance of less than 0.1 ohms. Amongst other things, SCP ensures
that the PSU shuts down should the 3.3V, 5V, and 12V rails short to any other rail, or to ground. It also ensures
that no damage should occur to the unit, or your PC’s components in the event of a short.
• Over Power Protection (OPP)
Over power protection shuts off the PSU when the power drawn is between 115% and 135% of the rated power.
• Catastrophic Failure Protection
PSU must have protection circuitry to shut down safely to prevent damage from any catastrophic failures such
as flame, excessive smoke, charred PCB, fused PCB conductor, startling noise, emission of molten material, etc.
TABLE OF CONTENTS
INSTALLATION
RM1000e
RM850e
RM750e

Corsair RM1000e Specifications

General

Wattage	1000W
Efficiency Rating	80 PLUS Gold
Modular	Fully Modular
Form Factor	ATX
Fan Size	140mm
Zero RPM Mode	Yes
MTBF	100, 000 hours
EPS Connectors	2
PCIe Connectors	6
ATX Connector	1
Fan Bearing	Fluid Dynamic Bearing
Input Voltage	100-240V
Input Frequency	47-63Hz
Output	+3.3V@20A, +5V@20A, +12V@83.3A, -12V@0.3A, +5Vsb@3A
Dimensions	150mm x 86mm x 160mm
Operating Temperature	0°C to 50°C
Fan Bearing Type	Fluid Dynamic Bearing
Connectors	1 x ATX, 2 x EPS, 6 x PCIe, 4 x Peripheral
Protections	OVP (Over Voltage Protection), UVP (Under Voltage Protection), SCP (Short Circuit Protection), OTP (Over Temperature Protection), OPP (Over Power Protection)
