Corsair RM550x User Manual

1 2
RMx SERIES
™
RMx SERIES
™
Product Specifications
RMx ........................ 
RMx .......................... 
RMx .......................... 
RMx .......................... 
RMx ........................ 
Installation .................. 
Warranty ..................... 
SafetyandAgency
Approvals .................... 
Congratulations on the purchase of your new Corsair
RMx Series High Performance ATX power supply.
Corsair RMx Series enthusiast power supplies are optimized for silence,
with a custom fan design and Zero RPM Fan Mode. 80 PLUS Gold rated
eciency ensures low-cost operation, and the fully modular black
cables allow for fast, neat builds. All Japanese 105°C capacitors make
it a great choice for high performance PCs where reliability is essential.
Safety and protection
• Over-voltage protection (OVP)
Over-voltage protection for the 12V, 5V and 3.3V DC outputs
is required to comply with the ATX specification. OVP shuts
down the PSU in the event that the DC outputs exceed a set
level, determined by the PSU manufacturer. The minimum
voltage levels required for compliance are 13.4V for the
+12V rail(s), 5.74V for the +5V rail and 3.76V for the 3.3V rail.
• Over-current protection (OCP)
The RMx Series features OCP on the 3.3V, 5V and 12V rails.
OCP ensures that the output of the DC voltage rails remains
within safe operating limits.
• Over-temperature protection (OTP)
OTP ensures that the PSU will shut down when the internal
temperature reaches a set point. This is usually as a result
of internal current overloading or a fan failure.
• Short-circuit protection (SCP)
A short-circuit is defined as any output impedance of less than
0.1 ohms. Amongst other things, SCP ensures that the PSU shuts
down should the 3.3V, 5V and 12V rails short to any other rail, or to
ground. It also ensures that no damage should occur to the unit, or
your PC’s components in the event of a short.

Corsair RM550x Specifications

General

Efficiency	90 %
Total power	550 W
AC input voltage	- V
Cabling type	Fully-Modular
Motherboard power connector	20+4 pin ATX
Floppy drive power connector	1
EPS power connector (4+4 pin)	Yes
Number of SATA power connectors	6
PCI Express power connectors (6+2 pin)	2
Peripheral (Molex) power connectors (4-pin)	4
Purpose	PC
ATX version	2.4
EPS version	2.92
Noise level	- dB
Bearing technology	Rifle
80 PLUS certification	80 PLUS Gold
Mean time between failures (MTBF)	100000 h
Continuous output rated temperature	50 °C
Power supply unit (PSU) form factor	ATX
Cooling type	Active
Fan diameter	140 mm
Fan location	Top
Illumination	-
Product color	Black
Number of fans	1 fan(s)
Cables included	AC

Weight and Dimensions

Depth	150 mm
Width	160 mm
Height	86 mm
