MOBILTEX® DATA LTD.
Calgary, Alberta
www.corTalk.com
TITLE: uDL1 Configuration and Operation Guide
DOCUMENT NO.:
UDL1-MAN-001
A. uDL1 Equipment Specifications
Operating Temperature -20 to +60 C (-4 to +140 F)
Charging Temperature 0 to +40 C (32 to +104 F)
Storage Temperature -40 to +70 C (-40 to +158 F)
Humidity 0 to 100% RH non-condensing
Maximum Altitude 5000 meters above sea level
Pollution Degree 1
Size 89mm x 40mm x 18mm (3.5” x 1.6” x 0.72”)
Weight 75 grams (2.7 oz)
Enclosure UV stable, wide temperature polycarbonate
Measurement Type Category 2 (as per CSA C22.2 – 61010)
Analog Ranges (DC & AC) +/- 150mVDC, 110mV true RMS AC, 150mVpeak
+/- 20VDC, 14V true RMS AC, 20Vpeak
+/-150VDC, 106V true RMS AC, 150Vpeak
AC Rejection on DC Readings >65dB @ 50/60Hz
Input Impedance >20Mohm
External Analog Channels 1 galvanically isolated, high impedance
Lightning Immunity Survives multiple 20KV 10mS surges
Temp. Measurement Accuracy +/-4 C (+/-7 F) over -20 to +60 C (-4 to +140 F)
DC Measurement Accuracy over -20 to +60 C (-4 to +140 F)
low range: +/-0.25% + 100uV
med range: +/-0.5% + 12mV
high range (-75V to +75V): +/-0.5% + 100mV
high range (<-75V and >+75V): +/-1% + 100mV
AC Measurement Accuracy over -20 to +60 C (-4 to +140 F)
low range: +/-0.3% + 80uV, 180uV floor
med range: +/-0.65% + 10mV, 22mV floor
high range (-75V to +75V): +/-0.65% + 80mV, 170mV floor
high range (<-75V and >+75V): +/-1% + 80mV, 170mV floor
Accuracy Aging +/-0.13% per year
ADC Resolution 16 bits
Memory Size Up to 500,000 readings (Basic model)
Up to 1,000,000 readings (Advanced G1 model)
Up to 2,000,000 readings (Advanced G2 model)
Battery Internal Li-Ion (Not user replaceable)
GPS Receiver 20-channel SiRFStarIII (Advanced G1 model)
72-channel u-blox M8 (Advanced G2 model)
Output File Data Resolution 1uV for AC and DC readings
0.1 for temperature readings
0.00001 for GPS position
Technical assistance may be obtained from:
Attn: Service Department
Mobiltex Data Ltd.
3640-26
th
Street NE
Calgary, AB T1Y 4T7
Canada
Tel: (403)291-2770
Main Website: http://www.cortalk.com
Service Website: http://www.mobiltex.com/service
