Cortex Multi Gym SM25 - Step 9

16 | ASSEMBLY INSTRUCTIONS
STEP 9
1. Secure 2x part 18 onto part 11 using:
- 3x part 74 - 6x part 85 - 3x part 83
2. Repeat step 1 for the other side.
74
85
83
M10 x 70mm
Φ 10
M10
8pcs
16pcs
8pcs
3. Secure 2x part 17 onto part 11 and part 1 using:
- 1x part 74 - 2x part 85 - 1x part 83
4. Repeat step 2 for the other side.
83
74
18
18
11
85
85
17
17
83
83
85
85
74
74
